38-Gallon Blanketed Lowboy Side-Connect Electric Water Heater - 6 Year Warranty

Model 6-40-EOMBS-E 100
Capacity (Gallons)
First Hour Rating
Blanket
Limited Tank Warranty

  • 6-year limited tank & parts warranty, 1-year labor warranty
  • Dual 4,500-watt heating elements deliver a first hour rating of 57 gallons with Uniform Energy Factor of 0.94
  • Compliant with HUD standards for mobile homes/manufactured housing

    • 38-Gallon Blanketed Lowboy Side-Connect Electric Water Heater - 6 Year Warranty
    Model 6-40-EOMBS-E 100
    Find a Local Retailer
    Find a Local Retailer
    Product Details
    • 6-year limited tank & parts warranty, 1-year labor warranty
    • Dual 4,500-watt heating elements deliver a first hour rating of 57 gallons with Uniform Energy Factor of 0.94
    • Compliant with HUD standards for mobile homes/manufactured housing
    • PEX dip tube helps reduce sediment build-up and maintain efficiency
    • Glass-lined tank with anode rod protects against corrosion
    • Factory-Installed temperature and pressure (T&P) relief valve
    • Shipped with Factory Insulation Blanket

      • The 6-40-EOMBS-E 38-Gallon Blanketed Lowboy Side-Connect Electric Water Heater is ideal for installations with limited space. This model features dual 4,500-watt commercial-grade heating elements to deliver reliable and efficient hot water.

    Specifications
    Tech Specs
    Nominal Gallon Capacity
    38 Gallons
    Rated Storage Volume
    35 Gallons
    UEF
    0.94
    Power Source
    ELECTRIC
    Limited Tank Warranty
    6 Years
    Limited Parts Warranty
    6 Years
    Water Connection Location
    SIDE
    Water Connection Size
    0.75"
    First Hour Rating
    57 Gallons
    ASME Certified
    No
    Blanket Included
    Yes
    Destination Country
    US
    Installation Type
    INDOOR
    Max Wattage
    4,500
    Number of Elements
    2
    Application
    RESIDENTIAL
    Shipping Height
    35.81
    Shipping Length
    28
    Shipping Width
    25
    Side Loop
    No
    Voltage
    240
    Dimension & Venting
    Type
    Water Heater
    Height
    31.25"
    Diameter
    24 in."
    Shipping Weight
    121 lbs
