75-Gallon Low NOx Power Direct Vent Liquid Propane Water Heater

Model 6-75-HRPDTL 311
Capacity (Gallons)
Fuel Source
First Hour Rating
Side Loop

  • 6-year limited tank & parts warranty, 1-year labor warranty
  • 76,000 BTU input for faster recovery
  • 129-gallon first hour rating
  • 75-Gallon Low NOx Power Direct Vent Liquid Propane Water Heater
    Model 6-75-HRPDTL 311
    Product Details
    • 6-year limited tank & parts warranty, 1-year labor warranty
    • 76,000 BTU input for faster recovery
    • 129-gallon first hour rating
    • State-of-the-art electronic gas control provides more precise temperature control
    • PEX dip tube reduces lime and sediment buildup and maximizes hot water output
    • Built-in heat traps on the water inlet and outlet reduce the amount of heat lost through piping
    • Environmentally-Friendly foam insulation reduces the amount of heat loss

    • The 6-75-HRPDTL 75-Gallon Low NOx Power Direct Vent Liquid Propane Water Heater features a two-pipe combustion system that draws clean air in from outside the home, eliminating any concerns about indoor ventilation.

      The 76,000 BTU propane burner delivers a first-hour rating of 129 gallons. An eco-friendly burner design reduces NOx emissions by up to 33% and complies with Low NOx emission requirements of 40 ng/J.

    Specifications
    Tech Specs
    Nominal Gallon Capacity
    75 Gallons
    Rated Storage Volume
    72 Gallons
    UEF
    0.68
    Thermal Efficiency
    82%
    Maximum BTUs
    76,000
    Power Source
    GAS
    Limited Tank Warranty
    6 Years
    Limited Parts Warranty
    6 Years
    T&P Relief Valve
    Yes
    Water Connection Location
    TOP
    Water Connection Size
    0.75"
    Emissions
    Low NOx
    First Hour Rating
    129 Gallons
    ASME Certified
    No
    Amperes
    5
    Blanket Included
    No
    Destination Country
    US
    Flue Diameter
    5.00
    Fuel Source
    PROPANE
    Height to T&P
    53.00
    Ignition Type
    Electronic Hot Surface Igniter
    Installation Type
    INDOOR
    Application
    RESIDENTIAL
    Shipping Height
    72.25
    Shipping Length
    35.2
    Shipping Width
    27.38
    Side Loop
    Yes
    Voltage
    120
    Dimension & Venting
    Type
    Water Heater
    Height
    60"
    Diameter
    26 in."
    Shipping Weight
    280 lbs
    Vent Type
    Power Direct Vent
